| ToF Lenses | ||||||||
| No. | Model |
Focal length
(mm)
|
Format | Mount |
Aperture
(F/#)
|
F.O.V
(H*V*D)
|
Resolution |
Dimension
(mm)
|
| 1 | UN-UW00216012C-MP | 2.16 | 1/4" | M12 | 1.2 | 84.4°*65.3°*103.3° | MP | φ14.00*L10.48 |
| 2 | UN-UW00247012C-5MP | 2.47 | 1/3" | M12 | 1.2 | 91.8°*69.8°*120.6° | 5MP | φ14.00*L13.73 |
| 3 | UN-UW033011C-MP | 3.3 | 1/3" | M12 | 1.1 | 74.5°*58°*90.7° | MP | φ12.00*L13.30 |
| 4 | UN-UW036012C-MP | 3.6 | 1/2" | M12 | 1.2 | 109.4°*78.7°*150.9° | MP | φ15.00*L18.46 |
| 5 | UN-UW053013C-MP | 5.3 | 1/2" | M12 | 1.3 | 75°*55°*95° | MP | φ14.00*L13.30 |
| 6 | UN-UW00776012C-MP | 7.76 | 1/2" | M12 | 1.2 | 48°*35.9°*60° | MP | φ18.00*L23.64 |
