UN-LFA1236C-10MP
UN-AT16014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT25014C-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT35014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-AT50014S-12MP
Product Features:
· Excellent edge sharpness and uniform illumination
· Designed to resist strong light interference, adaptable to complex lighting conditions
· Ultra-high resolution,accurately capture license plates and facial details
Product information: Custom designs are available upon request.
UN-TFA3520L-10MP
UN-TFA3528C-10MP
| Taurus Serisi Kompakt FA Lens( 10 MP) |
|||||
| Modeli |
UN-TFA3528C -10MP |
||||
| Odak uzaklığı |
35mm _ |
|
|||
| Diyafram |
F2.8-16 |
||||
| Görüntü formatı |
2,3 ″ |
||||
| Montaj |
C |
||||
|
Alan Açısı D x Y x D (°) |
|
2/3 ″ |
1/2 ″ |
1/3" |
|
| D |
18.39 ° |
1 3 . 4 ° |
10,1 ° |
||
| H |
14,8 ° |
1 0 . 8 ° |
8.10 ° |
||
| V |
11.1 ° |
8.10 ° |
6.10 ° |
||
| Optik Bozulma |
-0. 172 %y=5,5 mm |
-0,0 77 %y=4,5 mm |
-0,0 45 %y=4,0 mm |
||
| MOD |
0,2 m~ ∞ |
||||
| Boyut |
Φ 28 * 36,17 mm |
||||
| 17,526 mm |
|||||
| Geri Odak Uzunluğu _ _ |
13,63 mm |
||||
| Operasyon |
Manuel İris |
||||
| Manuel odaklanma |
|||||
| Tasarım Dalga Boyu |
420-1000 nm |
||||
| Konuyu Filtrele |
M27xP0.5 |
||||
 |
|||||
polarize olmayan küp kirişler (npbs)
